OTING

An all-terrain professional off-road SUV combining luxury comfort and intelligent safety

OTING

MODEL PARAMETERS

GET A QUOTE

MODEL PARAMETERS

Wheelbase (mm)

Maximum Power (kW)

Maximum Torque (Nm)

Displacement (mL)

Curb weight (kg)

FEATURES

Professional Part-time 4WD System
The system is simple in structure, stable, durable, and economically convenient to use.
Equipped with Eaton Front/Rear Electronic Locking Differential
Easy operation, one-button locking, which can be easily handled by both off-road beginners and professionals, helping you get out of difficult situations with ease.
7 Driving Modes: Snow Mode, Mud Mode, Sand Mode, Sports Mode, ECO Mode, Manual Mode, Sports Mode.

OTING Specification

OTING
Fuel type			Gasoline
Drivetrain Configuration			Two-Wheel Drive	Four-Wheel Drive
Emission Standard			Euro 6
Vehicle Model Specifications			STD	UPR
Specification	L×W×H (mm)		488218501875
	Wheelbase (mm)		2850
	Track Width (Front/Rear) (mm)		1570/1570
	Minimum Turning Radius (m)		5.7
	Minimum Ground Clearance (mm)		215
	Curb weight of the vehicle (kg)		1890	1950
	Gross Vehicle Weight (G.V.W.) (kg)		2501
	Fuel Tank Capacity (L)		73
	Occupancy		5
	Approach Angle/Departure Angle (°)		32°/27°
Engine	Model		Mitsubishi 4K31 2.0TD
	Displacement (mL)		1997
	Maximum Power (kW)		168
	Maximum Torque (Nm)		360
	Transmission		8AT (common / sport / sonw field / sand field /mud field / ECO / AMT)
Driving Mechanism	Suspension		Front: Double fork arm + stabilizer bar
	Suspension		Rear: independent
	Braking System		Four wheel disc brake
	Tire		255/60 R18
	Parking brake		Electronic Parking Brake (EPB) + Auto Hold Function
	Driving Type	Time-sharing four-wheel drive	-	●
	Shift handle	Imitation leather	●	●
	Differential lock (electronically controlled mechanical type)	Front axle differential lock	-	●
		Rear axle differential lock	-	●
	Steering assist braking	Tank U-turn	-	●
Appearance	Front bumper	Chrome trim	●	●
	Front Windshield	Tinted glass + UV protection + heat insulation	●	●
	Front Windshield	Electric Heating	o	o
	Front windows	Tinted glass	●	●
	Rear windows/rear windshield/side windows/sunroof	Privacy glass	●	●
	Rear defroster	Timed protection feature	●	●
	Power windows	Driver's side one-touch + power; others power	●	●
	Side mirrors (body-colored)	Manual folding + power adjustment + turn signals	●	-
	Side mirrors (body-colored)	Auto-folding + power adjustment + turn signals + 360° camera + heating	O	●
	Anti-glare rearview mirror	Manual	●	●
	Anti-glare rearview mirror	Automatic	O	O
	Shark gill decoration	Chrome Finish	●	●
	Engine under guard		●	●
	Side steps	Fixed side steps	●	●
	Roof Rails		●	●
	Hood gas struts		●	●
	Antenna type	Shark Fin style	●	●
	Rear spoiler		●	●
	Front tow hook		●	●
	Headlights	LED (auto-leveling, auto on/off, daytime running lights, follow-me-home function)	●	●
	Tail light assembly	LED	●	●
	Interior lights	2 units	●	●
	Front footwell ambient lighting	2 units	●	●
	Door panel lights	Front doors	●	●
	Door panel lights	Rear doors	-	o
	High-mount brake light	LED	●	●
	Trunk light		●	●
	License plate light	2 units	●	●
Comfort	Leather-wrapped steering wheel		O	O
	Multifunction steering wheel		●	●
	Steering system	Electric power steering (EPS)	●	●
	Central door locks		●	●
	Smart key	Remote key (unlock/lock/vehicle finder) + keyless entry + push-button start	●	●
	10-inch central control screen		●	-
	13-inch central control screen		O	●
	Smartphone connectivity	Supports iOS and Android	●	●
	Seat upholstery	Leatherette	●	●
	Seat upholstery	Genuine leather	o	o
	Driver's seat adjustment	6-way manual adjustment	●	-
		8-way power adjustment	O	●
		Heated seats	●	●
	Passenger Seat adjustment	4-way Manual adjustment	●	●
		4-way Power adjustment	O	O
		Heated seats	●	●
	Second-row seats	Heated seats	O	O
	Seatbelts	Front pretensioned 3-point seatbelts (height adjustable, unfastened reminder)	●	●
	Seatbelts	Rear pretensioned 3-point seatbelts	●	●
	ISOFIX child seat anchors	Rear left + rear right	●	●
	Rear air vents		●	●
	Rear headrest type	3 independent headrests	●	●
	Rear center armrest	With cup holders	●	●
	Rear seat configuration	60/40 split, adjustable backrest recline	●	●
Convenience	Auto start-stop		●	●
	Driver information display	3.5-inch	-	-
	Driver information display	7-inch LCD	●	●
	Speakers	4 units	●	●
	Speakers	6 units	O	O
	12V power outlets	2 outlets: 1 front, 1 in trunk	●	●
	USB ports	2 ports: 1 front, 1 rear	●	●
	Wireless charging pad		O	O
	Interior color schemes	Black/brown color scheme	●	●
	Interior color schemes	Brown/beige color scheme	-	-
	Sun visors	Driver: Sun visor (vanity mirror + lighting) Sun visor (makeup mirror + makeup mirror lighting)	●	●
	Sun visors	Passenger: Sun visor (vanity mirror + lighting) sun visor (makeup mirror + makeup mirror lighting)	●	●
	Interior assist handles	1 passenger-side + 1 each rear left/right (roof)	●	●
	Entry assist handles	1 passenger-side (A-pillar), 2 rear	●	●
	Trunk cargo hooks	4 units	●	●
	Power sunroof		●	●
	Power liftgate		o	o
Safety	Airbags	Driver + passenger	●	●
	Side airbags	Front row	○	○
	Side curtain airbags	Curtain-type	○	○
	Knee airbag	Driver	○	○
	Engine immobilizer		●	●
	Electronic Stability Control (ESC)	Anti-lock Braking System (ABS)	●	●
		Electronic Brakeforce Distribution (EBD)	●	●
		Vehicle Dynamic Control (VDC)	●	●
		Traction Control System (TCS)	●	●
		Hill Descent Control (HDC)	●	●
		Hydraulic Brake Assist (HBA)	●	●
		Roll Movement Intervention (RMI)	●	●
		Hill Start Assist (HSA)	●	●
		Emergency Brake Warning (EBW)	●	●
		Auto Vehicle Hold (AVH)	●	●
		Dynamic Parking Control	●	●
		Engine Drag Control (EDC)	●	●
	Cruise control		●	●
	Parking sensors	4 units	●	●
	Tire Pressure Monitoring System		●	●
	Backup camera	With dynamic guidelines	●	-
	360° surround view	Central display screen	o	●
	Transparent chassis view	540° surround view, central display screen	o	●
Note: ① "●" standard equipment; "-" not available; "o" optional; ② Final configuration subject to DMS system confirmation. Remarks: ①"●" standard configuration; "-" No such equipment; "o" optional; ② The order is subject to the DMS system activation project.

OTING
Fuel type			Gasoline
Drivetrain Configuration			Two-Wheel Drive	Four-Wheel Drive
Emission Standard			Euro 6
Vehicle Model Specifications			STD	UPR
Specification	L×W×H (mm)		488218501875
	Wheelbase (mm)		2850
	Track Width (Front/Rear) (mm)		1570/1570
	Minimum Turning Radius (m)		5.7
	Minimum Ground Clearance (mm)		215
	Curb weight of the vehicle (kg)		1890	1950
	Gross Vehicle Weight (G.V.W.) (kg)		2501
	Fuel Tank Capacity (L)		73
	Occupancy		5
	Approach Angle/Departure Angle (°)		32°/27°
Engine	Model		Mitsubishi 4K31 2.0TD
	Displacement (mL)		1997
	Maximum Power (kW)		168
	Maximum Torque (Nm)		360
	Transmission		8AT (common / sport / sonw field / sand field /mud field / ECO / AMT)
Driving Mechanism	Suspension		Front: Double fork arm + stabilizer bar
	Suspension		Rear: independent
	Braking System		Four wheel disc brake
	Tire		255/60 R18
	Parking brake		Electronic Parking Brake (EPB) + Auto Hold Function
	Driving Type	Time-sharing four-wheel drive	–	●
	Shift handle	Imitation leather	●	●
	Differential lock (electronically controlled mechanical type)	Front axle differential lock	–	●
		Rear axle differential lock	–	●
	Steering assist braking	Tank U-turn	–	●
Appearance	Front bumper	Chrome trim	●	●
	Front Windshield	Tinted glass + UV protection + heat insulation	●	●
	Front Windshield	Electric Heating	o	o
	Front windows	Tinted glass	●	●
	Rear windows/rear windshield/side windows/sunroof	Privacy glass	●	●
	Rear defroster	Timed protection feature	●	●
	Power windows	Driver’s side one-touch + power; others power	●	●
	Side mirrors (body-colored)	Manual folding + power adjustment + turn signals	●	–
	Side mirrors (body-colored)	Auto-folding + power adjustment + turn signals + 360° camera + heating	O	●
	Anti-glare rearview mirror	Manual	●	●
	Anti-glare rearview mirror	Automatic	O	O
	Shark gill decoration	Chrome Finish	●	●
	Engine under guard		●	●
	Side steps	Fixed side steps	●	●
	Roof Rails		●	●
	Hood gas struts		●	●
	Antenna type	Shark Fin style	●	●
	Rear spoiler		●	●
	Front tow hook		●	●
	Headlights	LED (auto-leveling, auto on/off, daytime running lights, follow-me-home function)	●	●
	Tail light assembly	LED	●	●
	Interior lights	2 units	●	●
	Front footwell ambient lighting	2 units	●	●
	Door panel lights	Front doors	●	●
	Door panel lights	Rear doors	–	o
	High-mount brake light	LED	●	●
	Trunk light		●	●
	License plate light	2 units	●	●
Comfort	Leather-wrapped steering wheel		O	O
	Multifunction steering wheel		●	●
	Steering system	Electric power steering (EPS)	●	●
	Central door locks		●	●
	Smart key	Remote key (unlock/lock/vehicle finder) + keyless entry + push-button start	●	●
	10-inch central control screen		●	–
	13-inch central control screen		O	●
	Smartphone connectivity	Supports iOS and Android	●	●
	Seat upholstery	Leatherette	●	●
	Seat upholstery	Genuine leather	o	o
	Driver’s seat adjustment	6-way manual adjustment	●	–
		8-way power adjustment	O	●
		Heated seats	●	●
	Passenger Seat adjustment	4-way Manual adjustment	●	●
		4-way Power adjustment	O	O
		Heated seats	●	●
	Second-row seats	Heated seats	O	O
	Seatbelts	Front pretensioned 3-point seatbelts (height adjustable, unfastened reminder)	●	●
	Seatbelts	Rear pretensioned 3-point seatbelts	●	●
	ISOFIX child seat anchors	Rear left + rear right	●	●
	Rear air vents		●	●
	Rear headrest type	3 independent headrests	●	●
	Rear center armrest	With cup holders	●	●
	Rear seat configuration	60/40 split, adjustable backrest recline	●	●
Convenience	Auto start-stop		●	●
	Driver information display	3.5-inch	–	–
	Driver information display	7-inch LCD	●	●
	Speakers	4 units	●	●
	Speakers	6 units	O	O
	12V power outlets	2 outlets: 1 front, 1 in trunk	●	●
	USB ports	2 ports: 1 front, 1 rear	●	●
	Wireless charging pad		O	O
	Interior color schemes	Black/brown color scheme	●	●
	Interior color schemes	Brown/beige color scheme	–	–
	Sun visors	Driver: Sun visor (vanity mirror + lighting) Sun visor (makeup mirror + makeup mirror lighting)	●	●
	Sun visors	Passenger: Sun visor (vanity mirror + lighting) sun visor (makeup mirror + makeup mirror lighting)	●	●
	Interior assist handles	1 passenger-side + 1 each rear left/right (roof)	●	●
	Entry assist handles	1 passenger-side (A-pillar), 2 rear	●	●
	Trunk cargo hooks	4 units	●	●
	Power sunroof		●	●
	Power liftgate		o	o
Safety	Airbags	Driver + passenger	●	●
	Side airbags	Front row	○	○
	Side curtain airbags	Curtain-type	○	○
	Knee airbag	Driver	○	○
	Engine immobilizer		●	●
	Electronic Stability Control (ESC)	Anti-lock Braking System (ABS)	●	●
		Electronic Brakeforce Distribution (EBD)	●	●
		Vehicle Dynamic Control (VDC)	●	●
		Traction Control System (TCS)	●	●
		Hill Descent Control (HDC)	●	●
		Hydraulic Brake Assist (HBA)	●	●
		Roll Movement Intervention (RMI)	●	●
		Hill Start Assist (HSA)	●	●
		Emergency Brake Warning (EBW)	●	●
		Auto Vehicle Hold (AVH)	●	●
		Dynamic Parking Control	●	●
		Engine Drag Control (EDC)	●	●
	Cruise control		●	●
	Parking sensors	4 units	●	●
	Tire Pressure Monitoring System		●	●
	Backup camera	With dynamic guidelines	●	–
	360° surround view	Central display screen	o	●
	Transparent chassis view	540° surround view, central display screen	o	●
Note: ① “●” standard equipment; “-” not available; “o” optional; ② Final configuration subject to DMS system confirmation. Remarks: ①”●” standard configuration; “-” No such equipment; “o” optional; ② The order is subject to the DMS system activation project.
